The carpet style anti-theft antenna has a delicate structure, does not occupy the total area of large shopping malls, does not harm the overall reasonable layout of the store, and can have a reasonable anti-theft effect on goods. The most important thing is to achieve barrier free shopping for consumers and create a good shopping atmosphere for them. Generally, large and medium-sized supermarkets, high-end clothing stores, luggage and shoe stores, cosmetics stores, and other places with valuable items are more suitable for carpet anti-theft antennas, which have better monitoring effects and can effectively improve the service efficiency of the store, bringing customers a different consumption experience.

The new generation supermarket carpet anti-theft antenna system of Nanjing Rich Electronics can have more than three coils per host, which can not only adapt to single channels, but also be used for multi-channel applications without affecting its effectiveness.

Performance parameter table:

Host specifications

Height: 312mm

Width: 190mm

Thickness: 80mm

parameter

Input voltage: AC 220-240V 50-60Hz

Current consumption: (220V)<; 75Arm

Input power: (220V)<; 50W

Transmission frequency: 58kHz ± 200Hz

Actual high emission current: 20A peak

Receiving center frequency: 58kHz

Environmental temperature: 0 ° C to 50 ° C

Type: Carpet style anti-theft antenna

Usage: Used for clothing stores to protect products from loss with a frequency of 58KHZ

Advantage: A completely concealed system can ensure the beauty of the store and improve space utilization
