The buried anti-theft system provides a beautiful and protective acoustic magnetic anti-theft system for retail environments required by wide exits or open buildings. The system offers an open detection height of up to 1.5 meters and hides the anti-theft product protection mechanism. When the protected product passes through the detection area, it collects sound and alarm lights to notify the staff.

The installation of local anti-theft systems requires the antenna to be buried underground at the store entrance, which is a hidden type and minimizes the impact on store operations. Its antenna is thin and flat, and can be directly installed on concrete floors. Then, the antenna can be covered with flooring materials, simplifying the installation process. This solution is an ideal detection system for places where it is not desirable or strictly prohibited to use detection door systems or dig floors.

Specifications

Height: 350mm

Width: 220mm

Thickness: 80mm

parameter

Input voltage: AC 220-240V 50-60Hz

Current consumption: (220V)<; 75Arm

Input power: (220V)<; 50W

Transmission frequency: 58kHz ± 200Hz

Actual high emission current: 20A peak

Receiving center frequency: 58kHz

Environmental temperature: 0 ° C to 50 ° C
